Model ExF-1050B … ExF-1150B

Explosion-Proof LED Flood & Street Light 50–150 W, ExF Series

A flameproof LED light in flood, projector and street-light versions for gas groups IIA and IIB.

50 W to 150 W in two housing sizes
Ex d IIB T6 Gb for Zone 1 and Zone 2 (IIA and IIB gases)
IP67 and WF2 corrosion protection
Separate LED and driver chambers with their own cooling paths
Seat, wall, pendant or ceiling mounting; rotating bracket
Stainless exposed fasteners

Request price & datasheet See specifications

Specifications

Models	ExF-1050B / 1060B / 1070B / 1080B / 1100B / 1120B / 1150B
Power	50 / 60 / 70 / 80 / 100 / 120 / 150 W
Ex marking	Ex d IIB T6 Gb
Input voltage	AC 85–265 V, 47/63 Hz
Power factor	> 0.95
Luminous efficacy	110 lm/W
Colour temperature	3000–6000 K
CRI	Ra 70–90
Beam angle	90° / 120°
Ingress protection	IP67
Corrosion grade	WF2
Material	High-pressure die-cast aluminium, powder coated; galvanised steel bracket; tempered glass
Operating temperature	−30 °C to +50 °C
Rated life	> 80,000 h

Values are nominal. Custom wattages, colour temperatures, optics and input voltages are available — ask for the full datasheet and IES file.

The ExF comes in three optical versions on the same flameproof body: a floodlight, a narrow projector and a street-light head for plant roads.

Sizes and weights

Models	Power (W)	Size (mm)	Weight (kg)
ExF-1050B – 1070B	50 / 60 / 70	330 × 255 × 166	10.2
ExF-1080B – 1150B	80 / 100 / 120 / 150	446 × 306 × 166	14.5

The explosion-proof certificate for this series is supplied with the quotation.

Applications

Oil and gas processing areas
Chemical and pharmaceutical plants
Steel works and power plants
Gas stations and depots
Plant roads in hazardous areas

Frequently asked questions

Can it be used with hydrogen?

No. IIB covers ethylene and most hydrocarbons but not hydrogen or acetylene. For IIC gases use the BED or BDE507 series.
