Model BAD8599

Explosion-Proof LED Floodlight 50–600 W

A flameproof floodlight for Zone 1 and Zone 2 gas areas and Zone 21 dust areas, in nine power steps from 50 W to 600 W.

Ex d IIC T6 Gb / Ex tD A21 IP66 T80 °C — covers gas group IIC, which includes hydrogen and acetylene
50 W to 600 W in three housing sizes
Efficacy of at least 120 lm/W, colour temperature 3000–6500 K
Wide input of AC/DC 90–265 V; DC 24 V and AC/DC 36 V versions for mines
Constant-current driver with open-circuit, short-circuit and over-voltage protection
Thick aluminium U-bracket with stainless-steel screws for any aiming angle

Request price & datasheet See specifications

Specifications

Model	BAD8599
Rated power	50 / 100 / 150 / 200 / 250 / 300 / 400 / 500 / 600 W
Ex marking	Ex d IIC T6 Gb / Ex tD A21 IP66 T80 °C
Input voltage	AC/DC 90–265 V, 50 Hz (DC 24 V or AC/DC 36 V on request)
Power factor	0.95
Luminous efficacy	≥ 120 lm/W
Colour temperature	3000–6500 K
Ingress protection	IP66
Corrosion class	WF1 / WF2
Cable entry	G3/4" for Ø10–14 mm cable
Mounting	U-bracket with adjustable angle
Mounting height	2.5–15 m depending on power
Rated life	100,000 h
Standards	GB 3836.1, GB 3836.2, IEC 60079-0, IEC 60079-1, EN 60079-0, EN 60079-1

Values are nominal. Custom wattages, colour temperatures, optics and input voltages are available — ask for the full datasheet and IES file.

The BAD8599 is the workhorse of our explosion-proof range. It is a flameproof floodlight built around an SMD LED array with a matrix layout. The LED chamber and the driver chamber are thermally separated, and the die-cast fins carry heat out of both through convection channels.

The front glass is high-strength, heat-resistant tempered glass with high light transmission. The driver is a constant-current, constant-power unit with a wide input range, so it tolerates the unstable supply common on remote industrial sites.

Sizes and weights

Power range	Housing size (mm)	Weight
50–150 W	245 × 210	4 kg
200–300 W	370 × 285	9 kg
400–600 W	430 × 350	12 kg

Applications

Oil refineries and petrochemical plants
Tank farms, fuel depots and loading bays
Chemical and pharmaceutical plants
Coal mines and grain or flour handling (combustible dust)
Paint shops and spray booths
Offshore and shipyard work areas

Frequently asked questions

Can the BAD8599 be used in Zone 1?

Yes. The Gb equipment protection level is suitable for Zone 1 and Zone 2 gas atmospheres, and the Ex tD A21 marking covers Zone 21 and Zone 22 dust atmospheres.

Is it ATEX or IECEx certified?

The standard version is certified to the Chinese GB 3836 standard, which follows IEC 60079. If your project needs ATEX or IECEx, tell us when you inquire and we will confirm availability and lead time for a certified version.
