Applications
- Corridors and stairwells
- Hotel rooms and hospitals
- Schools and homes
Model BG-XD
LED Ceiling Light 8–48 W
Dust- and insect-proof ceiling lights for corridors, rooms, hotels and hospitals.
- 8 W to 48 W
- Round Ø270 mm or rectangular 650 × 450 mm
- Sealed PMMA cover keeps out dust and insects
- Isolated driver with open, short and over-voltage protection
Specifications
| Models | BG-XDY08 / XDY12 / XDF30 / XD48 |
|---|---|
| Power | 8 / 12 / 30 / 48 W |
| Size | Ø270 mm (8, 12 W); 650 × 450 × 100 mm (30, 48 W) |
| Input voltage | AC 200–240 V, 50/60 Hz (100–240 V on request) |
| Power factor | > 0.9 |
| Colour temperature | 3000–6000 K |
| CRI | Ra 70–90 |
| LED | SMD5730 |
| Beam angle | 120° |
| Luminous efficacy | 90 lm/W |
| Material | PMMA cover + powder-coated steel base |
| Rated life | 50,000 h |
Values are nominal. Custom wattages, colour temperatures, optics and input voltages are available — ask for the full datasheet and IES file.
